记录一下自己得学习 和思考结果
主要是对于step 函数的应用，使用step 函数来替代if
// Copyright (c) 2017-2020 Xiamen Yaji Software Co., Ltd.
CCEffect %{
techniques:
- passes:
- vert: sprite-vs:vert
frag: sprite-fs:frag
depthStencilState:
depthTest: false
depthWrite: false
blendState:
targets:
- blend: true
blendSrc: src_alpha
blendDst: one_minus_src_alpha
blendDstAlpha: one_minus_src_alpha
rasterizerState:
cullMode: none
properties:
alphaThreshold: { value: 0.5 }
borderThickness: {value: 0.01 , editor: { silde: true ,range: [0 ,1.0] ,step: 0.01}}
borderColor: { value: [1.0, 1.0, 1.0, 1.0], editor: {type: color}}
}%
CCProgram sprite-vs %{
precision highp float;
#include <builtin/uniforms/cc-global>
#if USE_LOCAL
#include <builtin/uniforms/cc-local>
#endif
#if SAMPLE_FROM_RT
#include <common/common-define>
#endif
in vec3 a_position;
in vec2 a_texCoord;
in vec4 a_color;
out vec4 color;
out vec2 uv0;
vec4 vert () {
vec4 pos = vec4(a_position, 1);
#if USE_LOCAL
pos = cc_matWorld * pos;
#endif
#if USE_PIXEL_ALIGNMENT
pos = cc_matView * pos;
pos.xyz = floor(pos.xyz);
pos = cc_matProj * pos;
#else
pos = cc_matViewProj * pos;
#endif
uv0 = a_texCoord;
#if SAMPLE_FROM_RT
CC_HANDLE_RT_SAMPLE_FLIP(uv0);
#endif
color = a_color;
return pos;
}
}%
CCProgram sprite-fs %{
precision highp float;
#include <builtin/internal/embedded-alpha>
#include <builtin/internal/alpha-test>
#include <builtin/uniforms/cc-global>
in vec4 color;
uniform Constant{
vec4 borderColor;
float borderThickness;
};
#if USE_TEXTURE
in vec2 uv0;
#pragma builtin(local)
layout(set = 2, binding = 12) uniform sampler2D cc_spriteTexture;
#endif
vec4 frag () {
vec4 o = vec4(1, 1, 1, 1);
vec4 fcolor = vec4(1, 1, 1, 1);
#if USE_TEXTURE
o *= CCSampleWithAlphaSeparated(cc_spriteTexture, uv0);
#if IS_GRAY
float gray = 0.2126 * o.r + 0.7152 * o.g + 0.0722 * o.b;
o.r = o.g = o.b = gray;
#endif
float flowSpeed = 2.0;
// 这样 四个角颜色重叠
// float bottom = step(1.0 - borderThickness, uv0.y ); // uv0.y > 1.0 - borderThickness 取 1
// float top = (1.0 - step(borderThickness, uv0.y )) ; // uv0.y < borderThickness,取 0 ,用1减去， 就得到uv0.y < borderThickness 得1得效果
// 防止 四个角颜色重叠 bottom边和top边只绘制中间得那段线，重叠部分不显示
float bottom = step(1.0 - borderThickness, uv0.y ) * step(borderThickness ,uv0.x) * (1.0-step(1.0-borderThickness ,uv0.x)); // uv0.y > 1.0 - borderThickness 取 1
float top = (1.0 - step(borderThickness, uv0.y )) * step(borderThickness ,uv0.x) * (1.0-step(1.0-borderThickness ,uv0.x)); // uv0.y < borderThickness,取 0 ,用1减去， 就得到uv0.y < borderThickness 得1得效果
float left = (1.0 - step(borderThickness, uv0.x));
float right = step(1.0 - borderThickness, uv0.x);
float a = bottom + top + left + right ;
vec4 tempColor = mix(o, borderColor, a );
o *= tempColor;
vec4 t = vec4( a,a,a,1);
// 存在问题 当图片得尺寸不是1:1得时候，边框宽度不均匀
#endif
o *= color;
ALPHA_TEST(o);
return o;
}
}%
目前存在问题即图片不是1：1的化，边框的宽度不一致的情况
