引擎组刚刚提交了一个相关 PR ，可以考虑测试下
好的哦 我这边来测试下
我这边拉个空工程 重新测试了下
当 targetSdkVersion == 35时 还是会出现 上述所有的问题
当 targetSdkVersion 小于 35时 上面的输入框的位置能正常显示
/****************************************************************************
Copyright © 2010-2012 cocos2d-x.org
Copyright © 2013-2016 Chukong Technologies Inc.
Copyright © 2017-2018 Xiamen Yaji Software Co., Ltd.
Permission is hereby granted, free of charge, to any person obtaining a copy
of this software and associated documentation files (the “Software”), to deal
in the Software without restriction, including without limitation the rights
to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
copies of the Software, and to permit persons to whom the Software is
furnished to do so, subject to the following conditions:
The above copyright notice and this permission notice shall be included in
all copies or substantial portions of the Software.
THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
THE SOFTWARE.
****************************************************************************/
package com.cocos.lib;
import android.app.Activity;
import android.content.Context;
import android.content.Intent;
import android.graphics.Color;
import android.graphics.Paint;
import android.graphics.Rect;
import android.graphics.drawable.Drawable;
import android.graphics.drawable.ShapeDrawable;
import android.graphics.drawable.StateListDrawable;
import android.graphics.drawable.shapes.RoundRectShape;
import android.os.Build;
import android.os.Bundle;
import android.text.Editable;
import android.text.InputFilter;
import android.text.InputType;
import android.text.TextUtils;
import android.text.TextWatcher;
import android.util.Log;
import android.view.Gravity;
import android.view.KeyEvent;
import android.view.View;
import android.view.ViewGroup;
import android.view.ViewTreeObserver;
import android.view.WindowInsets;
import android.view.WindowManager;
import android.view.inputmethod.EditorInfo;
import android.view.inputmethod.InputMethodManager;
import android.widget.Button;
import android.widget.EditText;
import android.widget.RelativeLayout;
import android.widget.TextView;
import android.widget.Toast;
public class CocosEditBoxActivity extends Activity {
// a color of dark green, was used for confirm button background
private static final int DARK_GREEN = Color.parseColor("#1fa014");
private static final int DARK_GREEN_PRESS = Color.parseColor("#008e26");
private static CocosEditBoxActivity sThis = null;
private Cocos2dxEditText mEditText = null;
private Button mButton = null;
private String mButtonTitle = null;
private boolean mConfirmHold = true;
private int mEditTextID = 1;
private int mButtonLayoutID = 2;
/***************************************************************************************
Inner class.
**************************************************************************************/
class Cocos2dxEditText extends EditText {
private final String TAG = "Cocos2dxEditBox";
private boolean mIsMultiLine = false;
private TextWatcher mTextWatcher = null;
private boolean keyboardVisible = false;
private int mScreenHeight;
private boolean mCheckKeyboardShowNormally = false;
public Cocos2dxEditText(Activity context){
super(context);
this.setTextColor(Color.BLACK);
mScreenHeight = ((WindowManager) context.getSystemService(Context.WINDOW_SERVICE)).
getDefaultDisplay().getHeight();
mTextWatcher = new TextWatcher() {
@Override
public void beforeTextChanged(CharSequence s, int start, int count, int after) {
}
@Override
public void onTextChanged(CharSequence s, int start, int before, int count) {
}
@Override
public void afterTextChanged(Editable s) {
// Pass text to c++.
CocosEditBoxActivity.this.onKeyboardInput(s.toString());
}
};
registKeyboardVisible();
}
/***************************************************************************************
Public functions.
**************************************************************************************/
public void show(String defaultValue, int maxLength, boolean isMultiline, boolean confirmHold, String confirmType, String inputType) {
mIsMultiLine = isMultiline;
this.setFilters(new InputFilter[]{new InputFilter.LengthFilter(maxLength) });
this.setText(defaultValue);
if (this.getText().length() >= defaultValue.length()) {
this.setSelection(defaultValue.length());
} else {
this.setSelection(this.getText().length());
}
this.setConfirmType(confirmType);
this.setInputType(inputType, mIsMultiLine);
this.setVisibility(View.VISIBLE);
// Open soft keyboard manually. Should request focus to open soft keyboard.
this.requestFocus();
this.addListeners();
}
public void hide() {
mEditText.setVisibility(View.INVISIBLE);
this.removeListeners();
}
/***************************************************************************************
Private functions.
**************************************************************************************/
private void setConfirmType(final String confirmType) {
if (confirmType.contentEquals("done")) {
this.setImeOptions(EditorInfo.IME_ACTION_DONE | EditorInfo.IME_FLAG_NO_EXTRACT_UI);
mButtonTitle = getResources().getString(R.string.done);
} else if (confirmType.contentEquals("next")) {
this.setImeOptions(EditorInfo.IME_ACTION_NEXT | EditorInfo.IME_FLAG_NO_EXTRACT_UI);
mButtonTitle = getResources().getString(R.string.next);
} else if (confirmType.contentEquals("search")) {
this.setImeOptions(EditorInfo.IME_ACTION_SEARCH | EditorInfo.IME_FLAG_NO_EXTRACT_UI);
mButtonTitle = getResources().getString(R.string.search);
} else if (confirmType.contentEquals("go")) {
this.setImeOptions(EditorInfo.IME_ACTION_GO | EditorInfo.IME_FLAG_NO_EXTRACT_UI);
mButtonTitle = getResources().getString(R.string.go);
} else if (confirmType.contentEquals("send")) {
this.setImeOptions(EditorInfo.IME_ACTION_SEND | EditorInfo.IME_FLAG_NO_EXTRACT_UI);
mButtonTitle = getResources().getString(R.string.send);
} else{
mButtonTitle = null;
Log.e(TAG, "unknown confirm type " + confirmType);
}
}
private void setInputType(final String inputType, boolean isMultiLine){
mCheckKeyboardShowNormally = false;
if (inputType.contentEquals("text")) {
if (isMultiLine)
this.setInputType(InputType.TYPE_CLASS_TEXT | InputType.TYPE_TEXT_FLAG_MULTI_LINE);
else
this.setInputType(InputType.TYPE_CLASS_TEXT);
}
else if (inputType.contentEquals("email"))
this.setInputType(InputType.TYPE_TEXT_VARIATION_EMAIL_ADDRESS);
else if (inputType.contentEquals("number"))
this.setInputType(InputType.TYPE_CLASS_NUMBER | InputType.TYPE_NUMBER_FLAG_DECIMAL | InputType.TYPE_NUMBER_FLAG_SIGNED);
else if (inputType.contentEquals("phone"))
this.setInputType(InputType.TYPE_CLASS_PHONE);
else if (inputType.contentEquals("password")) {
if (Build.BRAND.equalsIgnoreCase("oppo")) {
mCheckKeyboardShowNormally = true;
}
this.setInputType(InputType.TYPE_CLASS_TEXT | InputType.TYPE_TEXT_VARIATION_PASSWORD);
}
else
Log.e(TAG, "unknown input type " + inputType);
}
private void addListeners() {
this.setOnEditorActionListener(new TextView.OnEditorActionListener() {
@Override
public boolean onEditorAction(TextView v, int actionId, KeyEvent event) {
if (! mIsMultiLine) {
CocosEditBoxActivity.this.hide();
}
return false; // pass on to other listeners.
}
});
this.addTextChangedListener(mTextWatcher);
}
private void removeListeners() {
this.setOnEditorActionListener(null);
this.removeTextChangedListener(mTextWatcher);
}
private boolean isSystemAdjustUIWhenPopKeyboard(int bottom) {
int bottomOffset = 0;
if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.M) {
bottomOffset = getWindow().getDecorView().getRootWindowInsets().getSystemWindowInsetBottom();
}
// view will be scrolled to the target position by system,
if (Math.abs(bottom - bottomOffset) < 10) {
return true;
}
return false;
}
private void registKeyboardVisible() {
getViewTreeObserver().addOnGlobalLayoutListener(new ViewTreeObserver.OnGlobalLayoutListener() {
@Override
public void onGlobalLayout() {
// API 30+ 由 WindowInsets 处理键盘（见 onCreate），这里不再 scrollTo，避免与系统重复位移
if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.R) {
return;
}
Rect r = new Rect();
getWindowVisibleDisplayFrame(r);
int heightDiff = getRootView().getHeight() - (r.bottom - r.top);
// if more than a quarter of the screen, its probably a keyboard
if (heightDiff > mScreenHeight/4) {
if (!keyboardVisible) {
keyboardVisible = true;
}
if (!isSystemAdjustUIWhenPopKeyboard(heightDiff)) {
getRootView().scrollTo(0, heightDiff);
}
} else {
getRootView().scrollTo(0, 0);
if (mCheckKeyboardShowNormally && !keyboardVisible) {
Toast.makeText(CocosEditBoxActivity.this, R.string.tip_disable_safe_input_type, Toast.LENGTH_SHORT).show();
}
if (keyboardVisible) {
keyboardVisible = false;
CocosEditBoxActivity.this.hide();
}
}
}
});
}
}
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
getWindow().setSoftInputMode(WindowManager.LayoutParams.SOFT_INPUT_ADJUST_RESIZE);
CocosEditBoxActivity.sThis = this;
ViewGroup.LayoutParams frameLayoutParams =
new ViewGroup.LayoutParams(ViewGroup.LayoutParams.MATCH_PARENT,
ViewGroup.LayoutParams.MATCH_PARENT);
RelativeLayout frameLayout = new RelativeLayout(this);
frameLayout.setLayoutParams(frameLayoutParams);
frameLayout.setClickable(true);
frameLayout.setOnClickListener(new View.OnClickListener() {
@Override
public void onClick(View view) {
CocosEditBoxActivity.this.hide();
}
});
setContentView(frameLayout);
this.addItems(frameLayout);
// 适配 Android 15/16 (targetSdk 35+) 强制 edge-to-edge：adjustResize 不再缩放窗口，
// 统一自己处理 IME insets：底部 padding = max(键盘高度, 导航栏高度)，输入条正好贴在键盘上沿。
if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.R) {
getWindow().setDecorFitsSystemWindows(false);
frameLayout.setOnApplyWindowInsetsListener(new View.OnApplyWindowInsetsListener() {
private boolean imeShown = false;
@Override
public WindowInsets onApplyWindowInsets(View v, WindowInsets insets) {
int ime = insets.getInsets(WindowInsets.Type.ime()).bottom;
int nav = insets.getInsets(WindowInsets.Type.navigationBars()).bottom;
v.setPadding(0, 0, 0, Math.max(ime, nav));
boolean visible = insets.isVisible(WindowInsets.Type.ime());
if (visible) {
imeShown = true;
} else if (imeShown) {
// 键盘被收起（返回键/输入法自身收起），与原逻辑一致关闭输入框
imeShown = false;
CocosEditBoxActivity.this.hide();
}
return insets;
}
});
}
Intent intent = getIntent();
Bundle extras = null;
if (null != intent) {
extras = intent.getExtras();
}
if(extras == null){
show("",
10,
false,
false,
"done",
"text"
);
} else {
show(extras.getString("defaultValue"),
extras.getInt("maxLength"),
extras.getBoolean("isMultiline"),
extras.getBoolean("confirmHold"),
extras.getString("confirmType"),
extras.getString("inputType"));
}
}
/***************************************************************************************
Public functions.
**************************************************************************************/
/***************************************************************************************
Private functions.
**************************************************************************************/
private void addItems(RelativeLayout layout) {
RelativeLayout myLayout = new RelativeLayout(this);
myLayout.setBackgroundColor(Color.argb(255, 244, 244, 244));
RelativeLayout.LayoutParams layoutParams = new RelativeLayout.LayoutParams(ViewGroup.LayoutParams.MATCH_PARENT,
ViewGroup.LayoutParams.WRAP_CONTENT);
layoutParams.addRule(RelativeLayout.ALIGN_PARENT_BOTTOM);
layout.addView(myLayout, layoutParams);
this.addEditText(myLayout);
this.addButton(myLayout);
}
private int dpToPixel(int dp) {
final float scale = getResources().getDisplayMetrics().density;
int px = (int) (dp * scale + 0.5f);
return px;
}
private void addEditText(RelativeLayout layout) {
mEditText = new Cocos2dxEditText(this);
mEditText.setVisibility(View.INVISIBLE);
mEditText.setGravity(Gravity.CENTER_VERTICAL);
mEditText.setBackground(getRoundRectShape(18, Color.WHITE, Color.WHITE));
mEditText.setId(mEditTextID);
int bottomPadding = dpToPixel(4);
int leftPadding = dpToPixel(3);
mEditText.setPadding(leftPadding,bottomPadding,leftPadding,bottomPadding);
RelativeLayout.LayoutParams editParams = new RelativeLayout.LayoutParams(
ViewGroup.LayoutParams.MATCH_PARENT, ViewGroup.LayoutParams.WRAP_CONTENT);
editParams.addRule(RelativeLayout.CENTER_VERTICAL);
editParams.addRule(RelativeLayout.LEFT_OF, mButtonLayoutID);
int bottomMargin = dpToPixel(5);
int leftMargin = dpToPixel(4);
editParams.setMargins(leftMargin, bottomMargin, bottomMargin, bottomMargin);
layout.addView(mEditText, editParams);
}
private void addButton(RelativeLayout layout) {
mButton = new Button(this);
RelativeLayout.LayoutParams layoutParams = new RelativeLayout.LayoutParams(ViewGroup.LayoutParams.WRAP_CONTENT, ViewGroup.LayoutParams.WRAP_CONTENT);
mButton.setTextColor(Color.WHITE);
mButton.setTextSize(16);
mButton.setBackground(getRoundRectShape(18, DARK_GREEN, DARK_GREEN_PRESS));
int paddingLeft = dpToPixel(5);
mButton.setPadding(paddingLeft,0,paddingLeft,0);
layoutParams.addRule(RelativeLayout.ALIGN_PARENT_RIGHT);
layoutParams.addRule(RelativeLayout.ALIGN_TOP, mEditTextID);
layoutParams.addRule(RelativeLayout.ALIGN_BOTTOM, mEditTextID);
layoutParams.rightMargin = dpToPixel(4);
layout.addView(mButton, layoutParams);
mButton.setGravity(Gravity.CENTER);
mButton.setId(mButtonLayoutID);
mButton.setOnClickListener(new View.OnClickListener() {
@Override
public void onClick(View v) {
CocosEditBoxActivity.this.onKeyboardConfirm(mEditText.getText().toString());
if (!CocosEditBoxActivity.this.mConfirmHold)
CocosEditBoxActivity.this.hide();
}
});
}
private Drawable getRoundRectShape(int radius, int normalColor, int pressColor) {
float[] outerRadii = new float[]{radius, radius, radius, radius, radius, radius, radius, radius};
RoundRectShape roundRectShape = new RoundRectShape(outerRadii, null, null);
ShapeDrawable shapeDrawableNormal = new ShapeDrawable();
shapeDrawableNormal.setShape(roundRectShape);
shapeDrawableNormal.getPaint().setStyle(Paint.Style.FILL);
shapeDrawableNormal.getPaint().setColor(normalColor);
ShapeDrawable shapeDrawablePress = new ShapeDrawable();
shapeDrawablePress.setShape(roundRectShape);
shapeDrawablePress.getPaint().setStyle(Paint.Style.FILL);
shapeDrawablePress.getPaint().setColor(pressColor);
StateListDrawable drawable = new StateListDrawable();
drawable.addState(new int[]{android.R.attr.state_pressed}, shapeDrawablePress);
drawable.addState(new int[]{}, shapeDrawableNormal);
return drawable;
}
private void hide() {
Utils.hideVirtualButton();
this.closeKeyboard();
finish();
}
public void show(String defaultValue, int maxLength, boolean isMultiline, boolean confirmHold, String confirmType, String inputType) {
mConfirmHold = confirmHold;
mEditText.show(defaultValue, maxLength, isMultiline, confirmHold, confirmType, inputType);
mButton.setText(mButtonTitle);
if (TextUtils.isEmpty(mButtonTitle)) {
mButton.setVisibility(View.INVISIBLE);
} else {
mButton.setVisibility(View.VISIBLE);
}
this.openKeyboard();
}
private void closeKeyboard() {
InputMethodManager imm = (InputMethodManager) getSystemService(this.INPUT_METHOD_SERVICE);
imm.hideSoftInputFromWindow(mEditText.getWindowToken(), 0);
this.onKeyboardComplete(mEditText.getText().toString());
}
private void openKeyboard() {
if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.R) {
mEditText.post(new Runnable() {
@Override
public void run() {
mEditText.requestFocus();
if (getWindow().getInsetsController() != null) {
getWindow().getInsetsController().show(WindowInsets.Type.ime());
}
InputMethodManager imm = (InputMethodManager) getSystemService(INPUT_METHOD_SERVICE);
imm.showSoftInput(mEditText, InputMethodManager.SHOW_IMPLICIT);
}
});
return;
}
InputMethodManager imm = (InputMethodManager) getSystemService(this.INPUT_METHOD_SERVICE);
imm.showSoftInput(mEditText, InputMethodManager.SHOW_IMPLICIT);
}
/***************************************************************************************
Functions invoked by CPP.
**************************************************************************************/
private static void showNative(String defaultValue, int maxLength, boolean isMultiline, boolean confirmHold, String confirmType, String inputType) {
GlobalObject.runOnUiThread(new Runnable() {
@Override
public void run() {
Intent i = new Intent(GlobalObject.getActivity(), CocosEditBoxActivity.class);
i.putExtra("defaultValue", defaultValue);
i.putExtra("maxLength", maxLength);
i.putExtra("isMultiline", isMultiline);
i.putExtra("confirmHold", confirmHold);
i.putExtra("confirmType", confirmType);
i.putExtra("inputType", inputType);
GlobalObject.getActivity().startActivity(i);
}
});
}
private static void hideNative() {
if (null != CocosEditBoxActivity.sThis) {
GlobalObject.runOnUiThread(new Runnable() {
@Override
public void run() {
CocosEditBoxActivity.sThis.hide();
}
});
}
}
/***************************************************************************************
Native functions invoked by UI.
**************************************************************************************/
private void onKeyboardInput(String text) {
CocosHelper.runOnGameThread(new Runnable() {
@Override
public void run() {
CocosEditBoxActivity.onKeyboardInputNative(text);
}
});
}
private void onKeyboardComplete(String text) {
CocosHelper.runOnGameThread(new Runnable() {
@Override
public void run() {
CocosEditBoxActivity.onKeyboardCompleteNative(text);
}
});
}
private void onKeyboardConfirm(String text) {
CocosHelper.runOnGameThread(new Runnable() {
@Override
public void run() {
CocosEditBoxActivity.onKeyboardConfirmNative(text);
}
});
}
private static native void onKeyboardInputNative(String text);
private static native void onKeyboardCompleteNative(String text);
private static native void onKeyboardConfirmNative(String text);
}
试试修改代码：C:\ProgramData\cocos\editors\Creator\3.8.3\resources\resources\3d\engine\native\cocos\platform\android\java\src\com\cocos\lib
